Cash Acme CM23276-0150 FVMX Series 1 in. Relief Valve

Product Description

The CASH ACME CM23276-0150 FVMX Series relief valve features an elastomer encapsulated disc with an electro less nickel plated seat. It is designed for commercial applications, with sizes from 2-1/2 ��� 12" / 65 ��� 300 mm and pressures up to 365 psi / 2517 kPa / 25 bar. Suitable for hot water systems.

• Features an elastomer encapsulated disc with an electro less nickel plated seat
• Sizes from 2-1/2 ��� 12" / 65 ��� 300 mm
• Pressures up to 365 psi / 2517 kPa / 25 bar

Product Highlights

The CASH ACME FVMX Series relief valve is ideal for commercial hot water applications, providing reliable pressure relief with its durable construction.

Product Information

Standard Information

• Brand: CASH ACME
• Manufacturer Part Number: CM23276-0150
• Country of Origin: Domestic

Technical Specifications

• ANSI: ANSI Z21.22
• ASME: ASME Section IV
• Application: Commercial
• CSA Certified: CSA 4.4
• Collection: FVMX Series
• End Connection 1: MNPT
• End Connection 2: FNPT
• End Connections: MNPT x FNPT
• Lead Law Compliance Level: Lead Free Not Certified, Approved for Non-Potable Water Applications
• Material: Bronze, Plastic
• Maximum Temperature: 210
• Pressure Class: 150#
• Recommended Valve Application: Hot Water
• Valve Body Material: Bronze
• Valve Disc Material: Silicone
• Valve Seat Material: Silicone
• Valve Size: 1 in
• Valve Type: Relief Valve
