Cash-Acme 16935-0150 3/4 Inch FVMX-8C Commercial Temperature and Pressure Relief Valve

Product Description

The Cash-Acme 3/4 Inch FVMX-8C commercial temperature and pressure relief valve ensures high-capacity protection for both domestic and commercial water heating systems. Designed for efficiency, the valve is fully automatic and resets after relieving pressure or temperature.

• Automatic reset feature for seamless operation
• Constructed with stainless steel elements in larger sizes
• Suitable for high-demand applications like hospitals and restaurants

Product Highlights

This valve is designed to offer reliable performance and meet the needs of high-volume water heating systems. Its ability to reseat after activation makes it a reliable component in preventing overpressure and overheating.

Product Information

Standard Information

• Set Pressures: 75 to 150 psi
• Temperature Relief: 210 degrees Fahrenheit (98.9 degrees Celsius)

Technical Specifications

• Inlet Type: Male NPT (MNPT)
• Outlet Type: Female NPT (FNPT)
• Max Temp: 210 degrees Fahrenheit
• Pressure Range: 75 to 150 psi
• Connection Type: Threaded
• Thermostat Length: 4.5 inches
• Pressure Set Point: 150 psi
• CSA Rating: 205,000 BTU/hr
• ASME Rating: 1,912,000 BTU/hr
