CARRIER ZR61K3E-PFV-950 Scroll Compressor

Product Description

The CARRIER ZR61K3E-PFV-950 is a hermetic scroll compressor designed for refrigeration systems. This unit operates using R-407C refrigerant and can utilize a power supply of 208-230 VAC single-phase. It features a stub-type suction line fitting with a seven-eighths inches outer diameter and a discharge connection with a half inches outer diameter. Lubrication is provided by Polyolester (POE) oil.

• Compressor type: scroll
• Operating refrigerant: R-407C
• Weight: 94.00 lbs

Product Highlights

This compressor is built for residential and commercial refrigeration applications, providing reliable performance and efficient operation.

Product Information

Standard Information

• Brand: CARRIER
• MPN: ZR61K3E-PFV-950

Technical Specifications

• Compressor Type: Scroll
• Refrigerant: R-407C
• Voltage: 208-230 VAC
• Phase: Single
• Frequency: 50/60 Hz
• BTU Output: 61,000
• Displacement: 5.04 in^3/Rev
• Oil Type: Polyolester (POE)
• Oil Charge Initial: 56 oz.
• Suction Line Size (OD): 7/8
• Discharge Connection Size (OD): 1/2
• Weight: 94.00 lbs
• Length: 9.69 inches
• Width: 9.69 inches
• Height: 17.75 inches
• Sound Level: 74-79 dBA
• Approvals: UL Recognized
• Mounting Dimensions: 7.5 x 7.5 x 18
