CARRIER ZPS26K5E-PFV-830 COMPRESSOR

Product Description

The CARRIER ZPS26K5E-PFV-830 is a hermetic scroll compressor designed for single-phase operation. This compressor operates efficiently using R-410A refrigerant and POE compressor oil. With a nominal capacity of 26400 tons, it offers an Energy Efficiency Ratio (EER) rating of 11.

• Single-phase power supply operation
• Compatible with R-410A refrigerant and POE oil
• Features a 1/2 inch discharge line and a 3/4 inch suction line

Product Highlights

This unit operates at a voltage of 208/230 V and has an amperage rating of 14.6 A. The height of the unit is 15.3 inches. A run capacitor, rated at 40 uF and 370 VAC, is necessary for operation.

Product Information

Standard Information

• Brand: CARRIER
• Type: Hermetic Scroll Compressor

Technical Specifications

• Amperage Rating: 14.6 A
• Compressor Oil: POE
• Dimensions: 15.3 inches in height
• Discharge Line Size: 1/2 inch
• EER Rating: 11
• Nominal Capacity: 26400 tons
• Refrigerant Type: R-410A
• Run Capacitor: 40 uF at 370 VAC
• Suction Line Size: 3/4 inch
• Voltage Rating: 208/230 V
