CARRIER ZP182KCE-TFD-855 Scroll Compressor

Product Description

The CARRIER ZP182KCE-TFD-855 is a scroll compressor suited for high-temperature air conditioning systems. It operates with R-410A refrigerant, delivering a nominal capacity of 182000 BTU/hour. This compressor can function on 380 to 240 Volt 50 Hertz, as well as 460 Volt AC 60 Hertz power supply. It features a three-lead, three-phase motor, achieving a cooling efficiency rating of 11.2 EER.

• Designed for high-temperature air conditioning systems.
• Operates with R-410A refrigerant and provides a nominal capacity of 182000 BTU/hour.
• Integrates features that minimize liquid refrigerant slugging and protect against debris-related failures.

Product Highlights

This compressor is engineered for durability and efficiency in demanding cooling applications.

Product Information

Standard Information

• Brand: CARRIER
• Compressor Type: Scroll

Technical Specifications

• Refrigerant Type: R-410A
• Nominal Capacity: 182000 BTU/Hour
• Voltage Rating: 380 to 240 Volt 50 Hertz, 460 Volt AC 60 Hertz 3-Phase
• Cooling Efficiency: 11.2 EER
• Discharge Connection: Horizontal, ID 7/8 inch
• Suction Connection: Horizontal, ID 1-3/8 inch
• Shipping Weight: 157 lbs
• Dimensions: 10.38 x 11.23 x 21.72 inches
