CARRIER P502-8165 Liquid Line Filter Drier

Product Description

The CARRIER P502-8165 is a liquid line filter drier suitable for HVAC and refrigeration systems. This unit is built with a compacted bead filter and a twenty-micron outlet pad for effective filtration. Made from durable copper, it offers sweat or braze connection types. The filter works with various refrigerants, including CFC, HCFC, and HFC, such as R-134a, R-404A, and R-507A. The connection size for both the inlet and outlet is five-eighths inch.

• Features a twenty-micron outlet pad for filtration.
• Compatible with CFC, HCFC, and HFC refrigerants.
• Constructed with solid copper fittings for easy installation.

Product Highlights

The CARRIER P502-8165 is an essential part for maintaining HVAC systems, ensuring that your cooling needs are met efficiently.

Product Information

Standard Information

• Brand: CARRIER
• Model: P502-8165

Technical Specifications

• Connection Size: 5/8 inch
• Material: Copper
• Length: 2.4 inches
• Width: 7.2 inches
• Height: 1.5 inches
• Weight: 1.25 lbs
• Composition: 75% molecular sieve, 25% activated alumina
• Max Working Pressure: 680 psi
• UL Listed: Yes
• Compatibility: R-134a, R-404A, R-507A
