CARRIER P045-31721K Compressor & Tubing Kit

Product Description

The CARRIER P045-31721K Compressor & Tubing Kit is suitable for heat pump and air conditioning applications. This unit uses Polyolester (POE) oil and R-410A refrigerant, operating efficiently at 200/230 VAC and 60 Hz. The rated load amps are 94.3, with a displacement of 49.7 cubic meters per hour and capable of producing a BTU output of 317,815. It includes a 1 1/8 inch outer diameter discharge connection and a 1 5/8 inch outer diameter suction line fitting, designed for both sweat and braze connections. The mounting dimensions are eleven inches by twelve inches, and the entire unit measures twenty-seven inches in length, twenty-five and a half inches in width, and forty-seven inches in height, weighing four hundred fourteen pounds.

• Engineered for low noise and minimal vibration.
• High efficiency for optimized performance in applicable systems.
• Compact and lightweight design for easier installation.

Product Highlights

Find high efficiency with the CARRIER P045-31721K, designed for superior cooling and heating performance.

Product Information

Standard Information

• Brand: CARRIER
• Model Number: P045-31721K

Technical Specifications

• Length: 27 inches
• Width: 25.5 inches
• Height: 47 inches
• Weight: 414 pounds
• BTU Output: 317,815
• Compressor Type: Hermetic Scroll
• Operating Voltage: 200/230 VAC
• Rated Load Amps (RLA): 94.3
