CARRIER HRP047T4LP6 Scroll Compressor

Product Description

The CARRIER HRP047T4LP6 is a scroll compressor suitable for refrigeration systems. This model runs on a three-phase, 460Vac power supply at a frequency of sixty Hertz. It is compatible with R407C refrigerant and offers a cooling capacity of 47,000 BTU.

• Compressor type: Scroll
• Cooling capacity: 47,000 BTU
• Power supply: 460Vac, three-phase

Product Highlights

Designed for reliable operation, the CARRIER HRP047T4LP6 efficiently handles refrigeration needs. It uses PVE oil for effective lubrication and includes spade terminals for easy electrical connections.

Product Information

Standard Information

• Brand: CARRIER
• Type: Scroll compressor

Technical Specifications

• Compressor Type: Scroll
• BTU Rating: 46 to 50 kBTU
• Refrigerant: R407C
• Voltage: 460
• Phase: 3
• Hertz: 60
• Oil: PVE (Polyvinylether)
• LRA: 50
• RLA: 7.7
• Suction Line Height: 10.8 inches
• Discharge Line Height: 15.9 inches
• Discharge Line Size: 1/2 inches
• Safety Standards: California Prop 65
• Operating Weight: 41 lbs
• Exterior Dimensions: 11 x 11 x 13 inches
• Shipping Weight: 41 lbs
