Carrier HN61KK324 Relay 24V Coil (Each) CRCHN61KK324

Product Description

Carrier HN61KK324 is an OEM pilot-duty relay that provides double-pole single-throw switching with a 24V coil and a 3 amp contact rating. The unit is intended for HVAC control circuits and measures approximately 2.7 x 2.1 x 1.8 inches. It uses screw connectors and supports DIN-rail mounting, and is sold individually as a replacement relay for compatible Carrier systems.

• DPST contact configuration with 24V coil and 3 amp contact rating
• Screw connector type and DIN rail mounting; dimensions 2.7 x 2.1 x 1.8 inches
• OEM Carrier part HN61KK324 (AllPoints OEM CRCHN61KK324), sold each

Product Highlights

DPST 24V pilot-duty relay, 3 A rating, compact 2.7 x 2.1 x 1.8 in, screw terminals, DIN-rail mount

Product Information

Standard Information

• Brand: CARRIER
• Manufacturer Part Number: HN61KK324
• Country of Origin: United States

Technical Specifications

• Brand: Carrier
• Manufacturer Part Number: HN61KK324
• AllPoints OEM Part Number: CRCHN61KK324
• Product Number: 8044373
• Description: Pilot-duty relay
• Product Type: OEM
• Dimensions (L x W x H): 2.7 x 2.1 x 1.8 in
• Coil Voltage: 24 V
• Contact Configuration: DPST (Double-Pole Single-Throw)
• Current Rating: 3 Amp
• Connector Type: Screw
• Mounting Type: DIN Rail Mount
• Manufacturer: Carrier Corporation
• Base Part Number: 13130528
• Unit of Stock: Each
