Carrier HN52TD024 contactor 2P-40FLA 24V 50/60Hz replaces HN52KD024

Product Description

The CARRIER HN52TD024 is a 2-pole definite purpose contactor designed for HVAC applications. It operates with a 24V AC coil at 50/60Hz and features a normally open, double-pole single-throw switch. This contactor is rated for 40 FLA and can handle a maximum voltage of 600V, making it suitable for various electrical control circuits. It replaces part number HN52KD024.

• 2-pole definite purpose contactor with 40A Full Load Amperage rating.
• Operates with a 24V AC coil at 50/60Hz frequency.
• Features 1/4" Quick Connect coil terminal connections.

Product Highlights

A 2-pole definite purpose contactor with 24V AC coil, 40A FLA, and 600V max voltage for HVAC systems.

Product Information

Standard Information

• Brand: CARRIER
• Manufacturer Part Number: HN52TD024
• Country of Origin: China

Technical Specifications

• Brand: CARRIER
• MPN: HN52TD024
• SKU: HN52TD024
• Condition: New
• Manufacturer: Hartland Controls
• Series: HCC
• Model Number: HCCY3AQ01UY103
• Type: Definite Purpose
• Poles: 2
• Switch Type: Double-Pole Single-Throw
• Circuit: Normally Open
• Max Voltage: 600V
• Coil Terminal Connections: 1/4" Quick Connect
• Coil Voltage: 24V AC
• Frequency: 50/60Hz
• Full Load Amperage (FLA): 40A
• Line Voltage (Single Phase, 120V): Horsepower: 2.0, Full Load Amperage: 25, Resistance: 35 Ohms
• Line Voltage (Single-Phase, 240V): Horsepower: 5.0, Full Load Amperage: 25, Locked Rotor Amperage: 150, Resistance: 35 Ohms
• Line Voltage (3-Phase, 240V): Full Load Amperage: 25, Locked Rotor Amperage: 150, Resistance: 35 Ohms
• Line Voltage (3-Phase, 480V): Full Load Amperage: 25, Locked Rotor Amperage: 125, Resistance: 35 Ohms
• Line Voltage (3-Phase, 600V): Full Load Amperage: 25, Locked Rotor Amperage: 100, Resistance: 35 Ohms
• Replaces Part Numbers: HN52KD024, 50HQ601003, 50VQ601003, HN52CD024, HN52CD026
• Approvals: CSA Listed
• Country of Origin: CHN
• Phase: Single
• Switching Voltage: 208-230 VAC
• Product Type: Air Conditioner, Packaged Unit/RTU, Heat Pump, Central Air Conditioner
• Compatible Brands: Bryant, Carrier
