Carrier HD46AR263 3/4 HP ECM Blower Motor

Product Description

The Carrier HD46AR263 is a 3/4 HP ECM blower motor designed for HVAC systems, particularly for furnaces. This motor efficiently converts electrical energy into mechanical energy to power the blower fan. It operates with variable speeds and is suitable for various installation scenarios. The motor has a frame diameter of five and five-eighths inches and features a shaft that extends three and a half inches with a half-inch diameter. The direction of rotation is clockwise when viewed from the shaft end.

• ECM blower motor for HVAC furnace systems.
• Rated at 3/4 HP with variable speed operation.
• Operates on 120/240V power.

Product Highlights

This product is ideal for HVAC professionals looking for a reliable and efficient blower motor for furnace applications.

Product Information

Standard Information

• HP Rating: 3/4
• Input Voltage: 120/240V

Technical Specifications

• Frame Diameter: 5 5/8 inches
• Shaft Length: 3.5 inches
• Shaft Diameter: 1/2 inch
• Rotation: Clockwise
