Carrier HC42GQ463 Motor OD 1/3 Hp ECM

Product Description

The CARRIER HC42GQ463 Motor OD 1/3 Hp ECM is a replacement part. It is manufactured by Broad Ocean with part number ZWK702B505007. This motor operates at 460V, 50/60Hz, and 1 phase, delivering 1/3 horsepower. It has a CW rotation and Class B insulation.

• Genuine OEM Parts
• In-House HVAC Techs
• Guarantees & Returns

Product Highlights

This motor is designed for continuous air over applications. Always check the fan blade to prevent premature motor failure due to vibration.

Product Information

Standard Information

• Brand: CARRIER
• Manufacturer Part Number: HC42GQ463

Technical Specifications

• Manufacturer: Broad Ocean
• Manufacturer Part #: ZWK702B505007
• Horsepower: 1/3
• Voltage: 460
• Hertz: 50/60
• Number of Phases: 1
• Amps: 1.4
• RPM: 1050
• Rotation: CW
• Shaft Length: 2"
• Height: 8-1/4"
• Length: 6-1/2"
• Continuous Air Over: True
• Class B Insulation: True
