CARRIER FLNR020.T - 20A 250V Time Delay RK5 Fuse

Product Description

The CARRIER FLNR020.T is a Class RK5 fuse specifically designed for HVAC disconnect switch applications. This fuse supports a current rating of 20 Amps and is suitable for both 250 VAC and 15 VDC power systems. It includes a time-delay feature, which is essential for specific circuit protection needs. The interrupting rating of this fuse is 20kA, ensuring reliability in case of faults.

• Rated for 20 Amps with dual voltage capability.
• Meets CSA and UL certification standards.
• Clip mounting with cartridge terminal type.

Product Highlights

This time-delay fuse serves various HVAC applications, protecting circuits from overload while ensuring the necessary safety and compliance standards are met.

Product Information

Standard Information

• Brand: CARRIER
• MPN: FLNR020.T

Technical Specifications

• Current Rating: 20 Amps
• Voltage: 250 VAC / 15 VDC
• Interrupting Rating: 20 kA
• Diameter: 0.562 inches
• Length: 2 inches
• Terminal Type: Cartridge
• Mounting: Clip
• Certifications: CE, CSA, QPL, UL
