CARRIER FILXXFNC0124 20x23x4 MERV 11 Air Filter

Product Description

The CARRIER FILXXFNC0124 is a pleated air filter designed for efficient air quality management. This filter features a MERV 11 rating, allowing it to effectively capture particles such as dust, pollen, and mold spores, ensuring cleaner air in your environment.

• Constructed with electrostatically charged synthetic gradient material.
• Fits FNCCAB fan coil filter cabinets.
• Resilient against temperatures up to 180F (82C) and peak conditions of 225F (107C).

Product Highlights

This filter is built with a moisture-resistant double-wall beverage board frame and a sturdy galvanized expanded metal grid for durability. It replaces parts like the Bryan/Carrier/Payne FILXXFNC-0024.

Product Information

Standard Information

• Brand: Carrier
• Type: Pleated

Technical Specifications

• MPN: FILXXFNC0124
• MERV Rating: 11
• Actual Dimensions: 19-7/8 x 22-5/8 x 4-5/16 inches
• Nominal Dimensions: 20 x 23 x 4 inches
• Max Temperature: 180F (82C) continuous service, peak at 225F (107C)
• Max Humidity: Resistant to 100% relative humidity
• Filter Media: Electrostatically charged 100% synthetic gradient media
• Filter Support Grid: 30 gauge galvanized expanded metal grid
