CARRIER A24 Air Conditioning Unit

Product Description

The CARRIER A24 is a packaged air conditioning unit suitable for residential and light commercial applications. This unit is designed with a single-piece structure that allows for easy installation. It uses Puron refrigerant, making it an eco-friendly choice. The unit is prewired, pre-piped, and pre-charged, which simplifies setup on site. The CARRIER A24 includes a scroll compressor and an ECM motor, contributing to efficient operation.

• Utilizes Puron refrigerant
• Features a scroll compressor and ECM motor
• Includes high and low pressure switches

Product Highlights

This unit is designed to provide reliable cooling with a tonnage of 2, making it effective for moderate temperature control.

Product Information

Standard Information

• Brand: Carrier
• MPN: A24

Technical Specifications

• Equipment Type: Straight Cool
• Tonnage: 2
• Cooling Rated Capacity: 24000 Btu/h
• SEER: 13
• EER: 11
• Voltage: 208-230 VAC
• Compressor Type: Scroll
• Air Flow Direction: Convertible
• Sound Level: 76 dBA
• CFM: 800
• Condenser Fan CFM: 2800
• Return Air Filter Size: 20 x 20 inches
• Dimensions: Width - 47 inches, Height - 40.125 inches, Length - 31.4375 inches
• Weight: 150 lbs
• Country of Origin: USA
