CARRIER 6BAB001611 Carlyle Control Module (CCM)

Product Description

The CARRIER 6BAB001611 Carlyle Control Module (CCM) is designed for protection and capacity control of screw compressors. This module ensures the correct configuration for various Carlyle compressor models. The CCM allows for the adjustment of control variables, setpoints, and protection settings. It maintains the system's control set-point by managing the slide valve operation while regulating compressor capacity. This control is focused on either suction pressure or temperature. Furthermore, the module optimizes efficiency through Vi Piston control tailored to specific compressor models.

• Controls compressor capacity via slide valve operation.
• Optimizes compressor efficiency using Vi Piston control.
• Provides motor and discharge temperature protection.

Product Highlights

This module is essential for maintaining system performance and reliability in HVAC applications.

Product Information

Standard Information

• Function: Compressor protection and capacity control
• Compatibility: Carlyle screw compressors

Technical Specifications

• Control Method: Slide valve or Vi piston
• Protection Features: Motor cooling, discharge temperature, oil level, and oil flow protection
• Sensor Failure Indication: Pressure transducer and temperature thermistor
