CARRIER 6510VUI Motor 1 HP 120/240V ECM Motor

Product Description

The CARRIER 6510VUI is a motor made for converting electrical energy into mechanical motion. This ECM (Electronically Commutated Motor) is a direct drive blower motor suitable for various HVAC applications. It is built to handle voltage inputs of one hundred twenty or two hundred forty volts and operates effectively at sixty hertz. The motor has a horsepower rating of one HP and reaches speeds of one thousand fifty RPM. It is also designed with Class B insulation for durability and longevity.

• Type: ECM (Electronically Commutated Motor)
• Voltage: 120/240 V
• Horsepower: 1 HP

Product Highlights

The CARRIER 6510VUI motor offers efficient performance for heating and cooling systems.

Product Information

Standard Information

• Manufacturer: Regal Rexnord - Genteq
• Product Type: Motor

Technical Specifications

• Input Voltage: 120/240 V
• Frequency: 60 Hz
• Horsepower: 1 HP
• Motor Speed: 1050 RPM
• Frame: 48Y
• Number of Phases: 1
• Rotation: Reversible
• Mounting Type: Round
• Enclosure Type: Open Air Over
• Dimensions: sixteen point one inches x six point nine five inches x seven point five inches
• Weight: 19.02 lb.
• Ambient Temperature: 40 Degrees C
• Insulation Class: B
• Duty: Continuous
• Motor Mounting Type: Band
• Motor Mounting Position: Vertical Shaft Down
• Motor Bearings: Ball
• Motor Thermal Protection: None
• Motor Shaft Rotation: CW/CCW
• Length Less Shaft: seven point six inches
• Enclosure: OAO
• RPM Range: 910-1200
• Shipping Dimensions: seven point six five inches height, fifteen point seven inches length, six point nine five inches width
• Shipping Weight: 19.01 lb.
• Country Of Origin: MX
