CARRIER 23XR05015401 Refrigerant Strainer

Product Description

The CARRIER 23XR05015401 is a refrigerant strainer suitable for industrial applications. It has 5/8 SAE inlet and outlet connections. This strainer features durable steel shells that provide shock resistance. Additionally, it includes full copper fittings, useful for soldering during the installation process. This unit is designed for high-pressure environments, with a maximum working pressure of 500 PSIG and a burst pressure of 2500 PSIG. It can operate continuously at a temperature of fifty-two degrees Celsius, or one hundred twenty-five degrees Fahrenheit. The strainer's dimensions are eight inches in length and three and a half inches in diameter, weighing approximately one point eight five pounds.

• Constructed with rugged steel shells for resistance to shock.
• Full copper fittings for easy soldering.
• Designed to minimize pressure drop with full flow fittings.

Product Highlights

This strainer ensures reliable performance in HVAC systems by maintaining clean refrigerant flow.

Product Information

Standard Information

• SKU: 23XR05015401
• Manufacturer: Emerson

Technical Specifications

• Inlet/Outlet: 5/8 SAE
• Maximum Working Pressure (MWP): 500 PSIG
• Maximum Allowable Pressure (MAP): 500 PSIG
• Burst Pressure: 2500 PSIG
• Continuous Operating Temperature: 52C (125F)
• Weight: 1.85 lbs
• Dimensions: 8 x 3.5 x 3.5 inches
• Shipping Weight: 2.09 lbs
