Carrier 1173699 Motor Condenser 208/230V 1 1/8 Hp 825 R

Product Description

The CARRIER 1173699 is a single-phase condenser motor designed for HVAC applications, operating at 208/230V. This 1 1/8 horsepower motor provides a consistent speed of 825 revolutions per minute, ensuring efficient air movement for condenser units. Its robust design and specific rotation (CWLE) make it suitable for various fan motor replacements, contributing to optimal system performance and longevity.

• Features a 1 1/8 horsepower rating and operates on 208/230V single-phase power.
• Delivers a rotational speed of 825 RPM with a Clockwise Lead End (CWLE) rotation.
• Designed as a 48Y frame condenser fan motor, suitable for specific HVAC system requirements.

Product Highlights

This CARRIER 1173699 condenser motor offers 1 1/8 HP power, 208/230V operation, and 825 RPM for reliable HVAC fan performance.

Product Information

Standard Information

• Brand: CARRIER
• Manufacturer Part Number: 1173699

Technical Specifications

• Brand: Carrier, ICP
• Horsepower: 1 1/8 Hp
• Voltage: 208/230V
• Phase: 1 PH
• RPM: 825 R
• Rotation: CWLE
• Frame: 48Y
• Motor Type: Condenser Fan Motor
• MPN: 1173699
