CARRIER 06EY7503DARP Semi-Hermetic Low Temp Compressor

Product Description

The CARRIER 06EY7503DARP is a semi-hermetic compressor suitable for low-temperature refrigeration systems. It is part of the 06EY series and provides efficient operation in demanding environments.

• Equipped with a high-flow, automatically reversible oil pump for lubrication.
• Features a crankcase venting system for pressure equalization during startup.
• Designed with contoured pistons and high-efficiency valves for improved refrigerant flow.

Product Highlights

This compressor delivers reliable performance for various refrigeration applications, including high, medium, and low-temperature environments.

Product Information

Standard Information

• Brand: CARRIER
• MPN: 06EY7503DARP

Technical Specifications

• Manufacturer Part Number: 06EY7503DARP
• Application: High Temp, Medium Temp, Low Temp
• Refrigerant Compatibility: R12, R22, R134a, R404A, R502, R507
• Connection Discharge: 1 1/8 inches
• Connection Suction: 2 1/8 inches
• Displacement: 50 CFM at 1750 RPM
• Horsepower: 15
• Number of Cylinders: 4
• Oil Charge: 14.0 Pint
• Voltage: 208-240/3, 460/3
• Dimensions: 24.00 x 33.00 x 20.00 inches
• Weight: 455 lbs
