CARRIER 06DR7256DC3250 Semi-Hermetic Compressor

Product Description

The CARRIER 06DR7256DC3250 is a semi-hermetic compressor designed for various temperature applications, including low temperatures. This compressor features an efficient oil pump that is automatically reversible and focused on positive-displacement oil lubrication. It has a crankcase venting system that helps equalize pressure during startup and ensures oil returns to the sump effectively.

• Equipped with a high-flow, automatically reversible oil pump.
• Includes a crankcase venting system for pressure equalization.
• High-efficiency valves for improved refrigerant flow and pressure management.

Product Highlights

This semi-hermetic compressor supports high-temperature, medium-temperature, and low-temperature applications using different refrigerants.

Product Information

Standard Information

• Brand: CARRIER
• MPN: 06DR7256DC3250

Technical Specifications

• Vendor Name: Carlyle (Genuine)
• Application: High Temp, Medium Temp, Low Temp
• Connection Discharge: 7/8 in
• Connection Suction: 1 3/8 in
• Displacement: 25 CFM at 1750 RPM
• Horsepower: 6 1/2
• Number of Cylinders: 6
• Oil Charge: 8.0 Pint
• Rated Load Amps: 28.2
• Refrigerant: R12, R22, R134a, R404A, R502, R507
• Voltage: 208-240/3
• Weight: 314 lbs
• Dimensions: 26 x 21 x 22 in
