Carlo Gavazzi GMB63H1PC3 Miniature Circuit Breaker 3 A (1 Pole)

Product Description

Carlo Gavazzi GMB63H1PC3 is a single-pole miniature circuit breaker that provides overcurrent protection rated 3 A at 277 V for DIN-rail installations. It is UL489 compliant and includes a C-curve trip characteristic with lug terminals and a 10 kA interruption rating for branch-circuit protection. Part of the GMB63 series, the device is intended for compact electrical panels and control equipment requiring DIN-mounted protection.

• Single-pole design with 3 A current rating and 277 V voltage rating
• C-curve trip characteristic with lug terminals and 10 kA interruption rating
• DIN-rail mounting; part of GMB63 series; UL489 certified

Product Highlights

Single-pole DIN-rail miniature circuit breaker, 3 A, 277 V, C-curve trip, lug terminals, 10 kA interruption, UL489

Product Information

Standard Information

• Brand: CARLO GAVAZZI
• Manufacturer Part Number: GMB63H1PC3

Technical Specifications

• Manufacturer: Carlo Gavazzi
• MPN: GMB63H1PC3
• Series: GMB63
• Product Type: Miniature circuit breaker
• Number of Poles: 1
• Current Rating: 3 A
• Voltage Rating: 277 V
• Trip Curve: C-curve
• Terminal Type: Lug terminals
• Interruption Rating: 10 kA
• Certifications: UL489
• Mounting Type: DIN rail mount
