Carlo Gavazzi GMB63H1PC15 Miniature Circuit Breaker 15 A (1P DIN Rail)

Product Description

The Carlo Gavazzi GMB63H1PC15 is a single-pole thermal-magnetic miniature circuit breaker rated 15 A, featuring a C-curve trip characteristic and lug terminals for DIN-rail mounting. It is UL 489 listed for branch-circuit protection in 240 VAC and 480Y/277 VAC systems and offers a lever actuator with a 10 kA interruption rating. Typical applications include industrial automation panels, branch circuit protection, and control and motor circuits.

• Thermal-magnetic trip unit with C-curve characteristic and 15 A rating
• DIN-rail mount with lug termination and lever actuator
• Approvals include UL 489; interruption rating 10 kA; suitable for 240 VAC and 480Y/277 VAC

Product Highlights

Single-pole 15 A thermal-magnetic MCB for DIN-rail panels with C-curve trip and 10 kA interruption rating

Product Information

Standard Information

• Brand: CARLO GAVAZZI
• Manufacturer Part Number: GMB63H1PC15
• Country of Origin: China

Technical Specifications

• Manufacturer: Carlo Gavazzi
• Manufacturer Part Number: GMB63H1PC15
• Product Type: Miniature Circuit Breaker
• Breaker Type: Thermal/magnetic
• Characteristic: C Curve
• Current Rating: 15 A
• Voltage Rating AC: 240 VAC; 480Y/277 VAC (277 VAC listed)
• Number of Poles: 1
• Mounting Type: DIN Rail Mount
• Terminal Type: Lug
• Actuator Type: Lever
• Approvals: UL 489; CSA C22.2 No 5; IEC 60947-2
• Interruption Rating: 10 kA
• Operating Temperature: -25 C to +55 C
• RoHS: RoHS3 Compliant
• Part Status: Active
• Illumination: None
• Weight: 0.3 lbs
• Dimensions: Height 109.3 mm; Length 53.4 mm; Width 54 mm
