Carlo Gavazzi GMB63H1PC10 Circuit breaker 10A (1P DIN rail)

Product Description

The Carlo Gavazzi GMB63H1PC10 is a thermal-magnetic miniature circuit breaker rated 10 A and intended for single-pole branch-circuit protection with DIN-rail mounting. It is suitable for operation up to 480/277 VAC, features a C trip curve and a lever actuator, and provides a 10 kA short-circuit capacity with lug terminal connections. The device is approved to UL489, IEC 60947-2, and CSA C22.2 No 5 standards.

• Thermal-magnetic trip mechanism with C trip characteristic; 10 A current rating
• Rated for 480/277 VAC operation, 10 kA short-circuit capacity, single pole (1P)
• DIN-rail mounting, lever actuator, lug terminal connections; approvals: UL489, IEC 60947-2, CSA C22.2 No 5

Product Highlights

1-pole thermal-magnetic 10 A breaker, C curve, 10 kA Icn, DIN-rail mount, UL/IEC/CSA approvals

Product Information

Standard Information

• Brand: CARLO GAVAZZI
• Manufacturer Part Number: GMB63H1PC10
• Country of Origin: China

Technical Specifications

• Manufacturer: Carlo Gavazzi
• Manufacturer Part Number: GMB63H1PC10
• Series: GMB63
• Product Type: Thermal magnetic miniature circuit breaker (MCB)
• Current Rating (Amps): 10 A
• Voltage Rating (AC): 480/277 VAC
• Number of Poles: 1 Pole (1P)
• Trip Curve: C
• Short-Circuit Capacity: 10 kA
• Mounting Type: DIN Rail
• Actuator Type: Lever
• Terminal Type: Lug terminals
• Breaker Type: Thermal Magnetic
• Approvals: UL489; IEC 60947-2; CSA C22.2 No 5
• Connection: Lug terminals
• Category: Circuit Protection - Circuit Breakers
• Base Product Number: GMB63H1
• Country of Origin: China
• Weight: 0.50 lb
