Carlin Combustion Technology 4020002S Control 4X4 15-Sec

Product Description

The Carlin Combustion Technology 4020002S is a burner primary control with interrupted duty, designed for use on EZ1/EZ2/EZ3/EZ66/99FRD/100CRD/102CRD/201CRD/301CRD/601CRD/701CRD/702CRD/801CRD/1050FFD/1150FFD oil burners. It features a 15-second trial for ignition and is thermostat/aquastat compatible. This oil primary control ensures safe and reliable operation.

• Used on EZ1/EZ2/EZ3/EZ66/99FRD/100CRD/102CRD/201CRD/301CRD/601CRD/701CRD/702CRD/801CRD/1050FFD/1150FFD Oil Burner
• 15-Second Trial for Ignition
• Thermostat/aquastat Compatible

Product Highlights

Burner primary control with 15-second trial for ignition, compatible with various oil burner models.

Product Information

Standard Information

• Brand: CARLIN COMBUSTION TECHNOLOGY
• Manufacturer Part Number: 4020002S

Technical Specifications

• CATALOG NUMBER: 4020002S
• Category: HVAC/R & Fans
• Description: Burner Primary Control; Item Primary Control, Interrupted Duty; Used On EZ1/EZ2/EZ3/EZ66/99FRD/100CRD/102CRD/201CRD/301CRD/601CRD/701CRD/702CRD/801CRD/1050FFD/1150FFD Oil Burner; Trial for Ignition 15 Second
• Item: Primary Control, Interrupted Duty
• Manufacturer Name: Carlin Combustion Technology
• Manufacturer Part Number: 4020002S
• Series/Model: 40200
• UNSPSC Code: 40101800
• Used On: EZ1/EZ2/EZ3/EZ66/99FRD/100CRD/102CRD/201CRD/301CRD/601CRD/701CRD/702CRD/801CRD/1050FFD/1150FFD Oil Burner
• Trial for Ignition: 15 Second
• Ohms: 15000
• Product Type: Oil Control
• Voltage: 120 V
• Amperage: 10 A
• Type: Burner Control, Oil Burner Controller
• Frequency: 60Hz
• Operating Temperature Range: 32F to 140F
• Approvals: UL & ULC
• Manufacturer: Carlin Combustion Technologies
• Brand: Carlin
• MPN: 4020002S
• Model: 4020002S
• Item Package Quantity: 1
• Batteries Included?: No
• Batteries Required?: No
• Condition: New
• Unit of Measurement: EA (Each)
• Production Status: Active
