CAPTIVEAIRE 00318OT3E56Z-S48PP-60HZ Motor - 3.00 HP

Product Description

The CAPTIVEAIRE Motor – 3.00 HP with MPN 00318OT3E56Z-S48PP-60HZ is a robust motor designed for three-phase applications. It operates at a frequency of sixty hertz and is suitable for use with voltages of 208-230/460V. This motor features an open drip-proof design and a rigid base, suitable for demanding environments.

• Direct replacement for part number 00318OS3E56Z-S40PP.
• Features include a 1735 RPM speed and a class F insulation.
• Equipped with a keyway and a shaft length of two and one-quarter inches.

Product Highlights

This motor is ideal for exhaust fan applications where durability is essential. The motor's specifications make it compatible with various HVAC systems.

Product Information

Standard Information

• Brand: CAPTIVEAIRE
• Part Number: 00318OT3E56Z-S48PP-60HZ

Technical Specifications

• Power: 3.00 HP
• Phase: Three Phase
• Voltage: 208-230/460V
• Frequency: 60 Hz
• Speed: 1735 RPM
• Frame Size: 56 Frame
• Full Load Amperage: 8.78-7.94 / 3.97 FLA
• Shaft Diameter: 7/8 inches
• Shaft Length: 2-1/4 inches
• Insulation Class: Class F
