CaptiveAire 00318OT3E56Z-S48PP-50HZ Motor - 3.00 Hp

Product Description

The CaptiveAire Motor with MPN 00318OT3E56Z-S48PP-50HZ is a three-phase motor designed for exhaust fan applications. It operates at 50 Hz and provides voltages of 190-220/380-415 V. This motor features an open drip-proof (ODP) design and a rigid base. With a frame size of fifty-six, it functions at 1410 RPM, making it suitable for various industrial settings.

• Direct replacement for part number 00318OS3E56Z-S40PP and CK56HB01A01.
• Keyway with a shaft length of two and one-quarter inches and a diameter of seven-eighths inches.
• Class F insulation for improved durability.

Product Highlights

This motor is ideal for applications requiring durable and efficient performance in exhaust systems.

Product Information

Standard Information

• Brand: CaptiveAire
• Manufacturer Part Number: 00318OT3E56Z-S48PP-50HZ

Technical Specifications

• Horsepower: 3.00 Hp
• Phase: Three Phase
• Frequency: 50 Hz
• Voltage: 190-220/380-415 V
• RPM: 1410
• Frame Size: 56
• FLA: 6.9-6.7 / 3.4-3.5
• Shaft Length: 2-1/4 inches
• Shaft Diameter: 7/8 inches
• Insulation Class: Class F
