Campbell lss4t 90 Degree Insert Elbow 1 Inch Stainless Steel

Product Description

The CAMPBELL lss4t is a 1 inch, 90-degree insert elbow fitting constructed from stainless steel. It is designed for use in barbed insert piping systems where a right-angle directional change is required. The smooth sweep channel through the elbow body reduces turbulence and minimizes friction loss, supporting efficient flow rates in pumping and fluid distribution applications. This fitting is installed by licensed plumbers and experienced pipe fitters working on water supply, irrigation, or fluid handling systems. The stainless steel construction provides corrosion resistance in both potable and non-potable water service environments.

This fitting is suited for residential and light commercial plumbing and irrigation applications where insert-style connections are used with flexible or semi-rigid tubing. The 90-degree sweep geometry makes it appropriate for tight routing changes within equipment enclosures, pump housings, and distribution manifolds. When joining this stainless steel fitting to threaded components, use stainless steel PTFE tape and a compatible pipe thread compound to ensure a leak-free seal on the threaded connections.

Key Features

• 90-degree smooth sweep channel minimizes friction loss and supports maximum flow efficiency
• 1 inch insert size for barbed tubing connections
• Stainless steel construction provides corrosion resistance in water service applications
• Compact footprint at 2.65 inches by 2.65 inches with a 1.2 inch height
• Limited warranty coverage included

Compatibility

Designed as an OEM-style replacement or direct-use insert elbow for standard 1 inch barbed tubing connections in residential and commercial plumbing and irrigation piping systems.

Installation Notes

Installation should be performed by a licensed plumber in accordance with applicable local plumbing codes and IPC guidelines. Shut off the water supply and relieve system pressure before removing or installing any fittings. When connecting to threaded ports, apply stainless steel PTFE tape and pipe thread compound to all male threads before assembly. Do not over-torque the fitting, as stainless steel threads can gall if excessive force is applied.
