Campbell 7100226 Fixed Shoulder Eye Bolt 6000 Lb

Product Description

The CAMPBELL 7100226 is a fixed shoulder eye bolt designed for vertical lifting applications in rigging, material handling, and heavy equipment work. Forged from C1030 steel, it delivers a rated lifting capacity of 6,000 lb on a 3/4-10 thread. The shoulder design resists side-loading better than shoulderless styles, making it the correct choice when the load may shift slightly off-axis. The shank measures 2 inches with a fully threaded 2-inch thread length and an overall length of 5.25 inches. Installed by riggers, millwrights, and maintenance professionals wherever a reliable, fixed anchor point is required.

This eye bolt is suited for industrial and commercial rigging setups where a permanent or semi-permanent lifting point is needed. Typical applications include overhead lifting of machinery, structural components, and heavy assemblies in manufacturing, construction, and maintenance environments. The 3/4-10 UNC thread fits standard tapped holes and compatible hardware across a wide range of rigging configurations. The 1.5-inch inside eye diameter accommodates shackles, hooks, and other standard rigging hardware.

Key Features

• 6,000 lb rated lifting capacity for demanding vertical lift applications
• Shoulder design provides resistance to angular and side loading compared to plain-shank eye bolts
• Fully threaded 2-inch shank on 3/4-10 UNC thread for secure fastening engagement
• Forged C1030 steel construction for strength and durability under repeated load cycles
• 1.5-inch inside eye diameter compatible with standard shackles and rigging hooks
• Overall length of 5.25 inches with a 2-inch shank length

Compatibility

Designed as a standard 3/4-10 UNC fixed shoulder eye bolt suitable for use with compatible rigging hardware, shackles, and hardware rated for 6,000 lb or greater working loads in overhead and vertical lifting applications.

Installation Notes

Installation should be performed by qualified riggers or maintenance professionals familiar with applicable ASME B30.26 rigging hardware standards. Always thread the bolt fully into the mating surface so the shoulder seats flush and snug against the load point before applying any lift. Never use a fixed eye bolt for angular or horizontal pulls beyond the rated angular capacity without de-rating the load appropriately. Inspect the eye, shank, and threads for deformation or wear before each use and remove from service if any damage is found.
