Product Description
The Camfil CityPleat filter, MPN 406455002, is designed for effective removal of both particulate matter and molecular contaminants in HVAC systems. This filter combines a particulate filter with activated carbon, specifically aimed at eliminating solid and gaseous pollutants. It is suitable for residential and commercial environments, primarily beneficial in urban settings where the air has lower concentrations of pollutants such as traffic and industrial emissions. The CityPleat offers a way to enhance existing HVAC systems and improve indoor air quality without the need for total system replacement.
- Combination filter for removal of particulates and odors/gases.
- Features Camfil RAD high-performance media technology.
- Constructed with a moisture-resistant beverage board frame.
Product Highlights
The CityPleat reduces both airborne particulates and unpleasant odors, making it ideal for enhancing air quality in various applications.
Product Information
Standard Information
-
Filter Frame: Rigid, water-resistant cardboard
-
Media: Synthetic/Activated Carbon
Technical Specifications
-
Max Temperature: 50 degrees Celsius
-
Relative Humidity: 30% - 70%
-
Dimension Standard: Filter dimensions according to EN 15805
-
Initial Resistance (CP200-20x20x2): 139 inches, w.g.
-
Rated Airflow (CP200-20x20x2): 1390 cfm
-
Nominal Size (CP200-20x20x2): 20x20x2 inches
-
Media Area (CP200-20x20x2): 7.89 ft²
