Camden Door Controls CM-54I Surface Mount Push Button

Product Description

The Camden Door Controls CM-54I is a surface-mount push button designed for access control and door activation applications. The unit measures 4.5 inches square and features a tri-color illuminated actuator in red, green, and blue, allowing installers to configure visual status indication at the point of entry. It is sold as a single unit and is typically specified by low-voltage technicians and access control integrators working on commercial door systems where ADA-compliant activation stations or egress push buttons are required.

The CM-54I suits commercial and institutional installations where a large-format, clearly visible push button is needed at an automatic door, vestibule, or access-controlled entry point. Its surface-mount design simplifies installation on standard wall boxes or directly to finished surfaces without requiring flush-mount cutouts. The tri-color LED illumination supports differentiated status signaling, making it appropriate for lobbies, corridors, and high-traffic entry points where visual feedback aids occupant navigation.

Key Features

• Surface-mount form factor simplifies installation on finished wall surfaces
• 4.5 inch square faceplate provides a large, visible activation target
• Tri-color illumination in red, green, and blue supports visual status indication
• Sold as a single unit suitable for individual door stations
• Appropriate for commercial access control and automatic door activation circuits

Compatibility

Designed as a surface-mount push button for commercial access control systems and automatic door operators requiring a low-voltage activation or egress station.

Installation Notes

Installation is typically performed by a licensed low-voltage or access control technician in accordance with applicable local codes and NEC Article 725 for Class 2 circuits. Power down and de-energize the door operator and access control panel before wiring the push button. Confirm the button voltage and current ratings are compatible with the connected controller before completing the circuit. Follow the manufacturer data sheet for wiring terminal assignments.
