Caleffi 6686C5S1A TwistFlow Manifold Assembly 3 Loop 1 Inch Brass Pre-Assembled

Product Description

The Caleffi 6686C5S1A is a pre-assembled 3-loop radiant manifold assembly, meticulously designed for efficient distribution in radiant heating systems. This robust assembly, crafted from high-grade brass, facilitates optimal control and heat emission in flooring systems.

• Comes pre-assembled with built-in shut-off valves and balancing valves.
• Incorporates sight flow gauges for enhanced monitoring.
• Supports 1-inch FNPT inlets and 3/4-inch MNPT outlets, ensuring compatibility with various piping configurations.

Product Highlights

This manifold assembly is engineered to withstand up to 150 psi of pressure and can operate efficiently at temperatures as high as 180 degrees Fahrenheit. The comprehensive design integrates essential components including automatic air vents and manifold brackets, which simplifies installation and ensures long-term durability.

Product Information

Standard Information

• Material: Brass
• Pressure Rating: 150 psi Working
• Temperature Rating: 180 degrees Fahrenheit Working

Technical Specifications

• Series: 668S1
• Type: Pre-Assembled
• Dimensions: 15-3/16 inches L x 13-15/16 inches H
• Inlet Size: 1 inch FNPT
• Outlet Size: 3/4 inch MNPT
• Number of Outlets: 3
