Calbrite S61000SC00 Strut Clamp 1 Inch 316 Ss

Product Description

The CALBRITE S61000SC00 is a 1-inch trade size strut clamp manufactured from type 316 stainless steel with a polished brite finish. It is designed to secure conduit or pipe to standard 1-5/8-inch strut channel in corrosive or sanitary environments. The clamp inserts into the two channel returns and can be positioned at any point along the slot side of the channel. It carries a 600-pound load rating and ships with a stainless steel nut and bolt. Material thickness is 0.075 inches and the included hardware is a 1/4-inch-20 TPI by 3/4-inch bolt. Licensed electricians and mechanical contractors install this fitting where stainless channel systems are specified.

This strut clamp is suited for industrial and commercial applications where corrosion resistance and sanitary compliance are required. Listed applications include food and beverage production, marine and coastal facilities, chemical plants, water and wastewater treatment, pharmaceutical and cosmetics manufacturing, refining and extraction sites, petrochemical operations, and pulp and paper mills. The 316 stainless steel construction and brite finish meet stringent sanitary conditions in wet, chemical-laden, or saltwater environments. It is designed specifically for use with standard 1-5/8-inch stainless strut channel.

Key Features

• Type 316 stainless steel construction resists corrosion in harsh chemical and marine environments
• Polished brite finish enhances corrosion resistance and meets sanitary appearance requirements
• 600-pound load rating for reliable support in structural channel applications
• Inserts at any point along the slot side of the channel for flexible positioning
• Includes stainless steel nut and 1/4-inch-20 TPI by 3/4-inch bolt
• UL listed

Compatibility

Designed for use with standard 1-5/8-inch stainless strut channel in trade size 1-inch conduit support applications.

Installation Notes

Installation is performed by licensed electricians or mechanical contractors following applicable NEC and facility code requirements. De-energize all circuits and isolate the conduit system before installing or adjusting clamps. Insert the clamp into the channel returns and tighten the hardware to secure the fitting without over-compressing the channel flange. Use hand tools rated for stainless steel fasteners to avoid galling the bolt threads.

Technical Specifications

• Trade Size: 1 inch
• Material: 316 Stainless Steel
• Finish: Brite
• Load Rating: 600 pounds
• Material Thickness: 0.075 inches
• Bolt Size: 1/4 inch-20 TPI x 3/4 inch
• Approval: UL
• Country of Origin: CN

Standard Information

• Brand: CALBRITE
• Manufacturer Part Number: S61000SC00
