CABLE 4/0-3C-W/GRD-CLX

Product Description

The CABLE 4/0-3C-W/GRD-CLX is a multi-conductor cable designed for power and control circuits in various applications. This cable features four AWG conductors and includes a grounding conductor, ensuring safety and reliability. It is built with shielding and robust jacketing to withstand environmental factors.

• Suitable for installation in cable trays, raceways, and direct burial.
• Can be utilized in both wet and dry locations.
• Rated for a voltage of six hundred volts.

Product Highlights

This cable is ideal for various electrical installations, including industrial and commercial applications.

Product Information

Standard Information

• Brand: CABLE
• MPN: 4/0-3C-W/GRD-CLX

Technical Specifications

• Conductor Size AWG: 4/0
• Number of Conductors: 3
• Ground Wire Size: 4 AWG
• Grounding Conductor(s): 3#8
• Voltage Rating: 600V
• Temperature Rating: 90C (194F)
• Outside Diameter: 1.73 inches
• Approx. Core O.D.: 2.24 inches
• Jacket Material: PVC - Polyvinyl Chloride
• Conductor Material: Bare Copper
• Insulation: XLPE - Cross Linked Polyethylene
• Allowable Ampacity: 260 Amps
• Weight per Foot: 0.914 lb
