Bussmann TPL-BF BUSS TPL-BF TELPOWER FUSE POWER 1 IN DIAMETER X 2.625 IN LENGTH

Product Description

The Bussmann TPL-BF is a telecommunication fuse designed for reliable power distribution. This fuse features a voltage rating of one hundred seventy volts direct current (DC) and an amperage rating of one hundred fifty amps. The TPL-BF has a current-limiting capability with an interrupt rating of one hundred kAIC. It uses a bolted blade end connection with silver-plated terminals. This design helps in protecting telecommunications equipment from high levels of current and potential damage.

• Current-limiting fuse
• Supports 170 VDC and 150 A
• Interrupt rating of 100 kAIC

Product Highlights

The Bussmann TPL-BF is suitable for various IT and datacom applications.

Product Information

Standard Information

• Brand: Bussmann
• Manufacturer: Bussmann Mfg.

Technical Specifications

• Voltage Rating: 170 VDC
• Amperage Rating: 150 A
• Interrupt Rating: 100 kAIC
• Body Size: 1 inch diameter x 2.625 inches length
• End Type: Bolted blade end
• Material: Silver
• Type: Current-limiting
• Indicating/Non-Indicating: Non-Indicating
