Bussmann TCF3RN 3 Amp Cube Fuse Power 600 VAC/300 VDC

Product Description

The Bussmann series TCF3RN is a 3 Amp cube fuse designed for reliable circuit protection in various applications. This fuse operates at 600 VAC and 300 VDC. It features a time-delay design, which is ideal for situations where temporary overloads might occur. The fuse is constructed with glass-filled polyethersulfone, ensuring durability and long-term performance.

• 3 Amp rating for optimal circuit protection
• Designed for use in electrical panelboards and industrial control
• Time-delay characteristics help reduce nuisance blowing

Product Highlights

This fuse is engineered to fit in a compact space while offering a high interrupting rating, suitable for critical electrical systems.

Product Information

Standard Information

• Brand: Bussmann
• Manufacturer: Bussmann Mfg.

Technical Specifications

• Amperage Rating: 3 A
• Voltage Rating: 600 VAC/300 VDC
• Interrupt Rating: 100/300 kA
• Type: Non-Indicating Time Delay
• Material: Glass Filled Polyethersulfone
• Body Size: 0.81 inches diameter x 3 inches length
• Mounting Type: Chassis/DIN Rail
• Response Time: 10 seconds at 500%
