Bussmann TB300-10 Barrier Block 30A 600V (10 Pole) Replacement MPN

Product Description

The Bussmann TB300-10 Barrier Block offers reliable performance for power distribution applications. Made by Bussmann, this panel mount terminal block is designed for effective electrical connections in various environments. The TB300-10 features a breakdown voltage of seven thousand five hundred volts and supports a voltage rating of six hundred volts at an amperage of thirty amps. This barrier block has ten poles and utilizes #8-32 TPI screws for secure connections.

• Ten-pole barrier design
• Breakdown voltage of 7500V
• Mounting type: screw

Product Highlights

This terminal block is suitable for machine equipment in factories and robotics applications.

Product Information

Standard Information

• Brand: Bussmann
• Manufacturer: Bussmann Mfg.

Technical Specifications

• Type: Panel mount terminal block
• Voltage Rating: 600 V
• Amperage Rating: 30 A
• Dimensions: 6.62 in length x 1.33 in width x 0.81 in height
• Screw Size: #8
• Screw Type: Phil-Slot
• Material: Brass
• Operating Temperature: -40 to 130 degrees C
