Bussmann T60060-1CR RM60600-1CR Fuse Block

Product Description

The Bussmann RM60600-1CR fuse block is a modular, single-pole Class R fuse block designed for use with knife blade cartridge fuses. It supports a voltage rating of 600V and an amperage range of 450 to 600A. Constructed from thermoplastic, it is suitable for use in temperatures ranging from -40 to 120 degrees Celsius.

• Modular design for easy installation and maintenance
• Accommodates 4 AWG to 500 kcmil wire sizes
• Durable thermoplastic construction

Product Highlights

The Bussmann RM60600-1CR fuse block is ideal for providing reliable overcurrent protection in various electrical applications.

Product Information

Standard Information

• Brand: BUSSMANN
• Manufacturer Part Number: T60060-1CR

Technical Specifications

• UNSPSC: 39121629
• Amperage Rating: 450 to 600 A
• Class: R
• Connection type: Knife Blade End
• Material: Thermoplastic
• Mounting type: Hole
• Number of Poles: 1
• Series: RM Series
• Suitable For Use With: Knife Blade Cartridge Fuse
• Temperature Rating (Degrees F): -40 to 120 deg C
• Type: Modular
• Voltage Rating: 600 V
• Wire Size: 4 AWG to 500 kcmil
