Bussmann S506-80-R Eaton Bussmann series time-delay fuse 0.08A

Product Description

The BUSSMANN S506-80-R is an Eaton Bussmann series time-delay fuse. This fuse is rated for 0.08A, 250 Vac or less, and 32 Vdc, with a 35 AIC interrupt rating at 250 Vac. It is designed for electronic circuits and features a glass tube with nickel-plated brass end cap construction.

• Time-delay fuse
• Glass tube
• Thermal Overload Protection

Product Highlights

Time-delay fuse with glass tube and nickel-plated brass end cap construction.

Product Information

Standard Information

• Brand: BUSSMANN
• Manufacturer Part Number: S506-80-R
• Country of Origin: China

Technical Specifications

• Product Name: Eaton Bussmann series time-delay fuse
• Catalog Number: BK/S506-80-R
• UPC: 051712649247
• Product Height: 20 mm
• Product Diameter: 5.2 mm
• Product Type: Time-delay fuse
• Amperage Rating: 0.08A
• Frequency rating - max: 50 Hz
• Frequency rating - min: 50 Hz
• Voltage drop: 580 mV maximum
• Interrupt rating: 35 AIC at 250 Vac
• Fuse indicator: Non-indicating
• Connection: Ferrule end x ferrule end
• Material: Glass tube Nickel-plated brass end cap construction
• Packaging type: Bulk
• Quantity: 100
• Voltage rating: 250 Vac or less, 32 Vdc (self certified)
• Type: Electronic
• Special features: Glass tube
• Application: Electronic circuits
• Fuse Body Type: Blade
• Current Type: AC/DC
• Features: Thermal Overload Protection
• Current Rating (Amps): 0.08A
• Voltage Rating: 250V
• Response Time: Time Delay
• Dimension: 5X20MM
• Series: S506
• AC Voltage Rating: 250 V
• Body Material: Glass
• Compatible Fuse Block Series: HTB
• Current Rating: 80 mA
• Element: Single
• Fits Fuse Block Style: Non-Rejection
• Fuse Body Style: Cylindrical
• Interrupt Rating - AC: 35 A
• Overall Diameter: 5 mm
• Overall Length: 20 mm
• Speed: Time-Delay
• Standards: cURus Recognition Guide JDYX2/JDYX8; IMQ; MITI/JET1641-31003-1005
• Visual Indication: Glass
• UNSPSC: 39121604
• Manufacturer: Eaton's Bussmann series
• Family Series: Eaton's Bussmann series Fuses
• Fuse Type: Miniature
• AC Voltage: 250 VAC
• DC Voltage: 32 VDC
• Characteristic: Time Delay
• Interrupt Rating: 35 A @ 250 V
