Bussmann NON-1 One Time Fuse 1 A 250 VAC 125 VDC

Product Description

The Bussmann NON-1 is a one-time fuse designed for light-duty circuit locations. This fuse provides protection in circuits where a considerable amount of temporary surges are not present. The NON-1 is a non-indicating, non-current limiting fuse rated at one ampere and operates at a voltage of 250 VAC and 125 VDC. With a cylindrical body measuring nine-sixteenths inch in diameter and two inches in length, it is engineered for reliability in power distribution systems.

• Amperage Rating: 1 A
• Interrupt Rating: 50 kA at 250 VAC and 125 VDC
• Standards: UL 248-9, CE, and CSA certified

Product Highlights

This fuse is suitable for light-duty applications and can handle short circuit currents that are relatively low. It is essential to consider that it should not be specified for circuits with large transients or motor overloads.

Product Information

Standard Information

• Product Type: One-Time Fuse
• Application: Light Duty Circuit Locations

Technical Specifications

• Fuse Class: K5
• Body Style: Cylindrical
• End Type: Ferrule
• Material: Melamine
• Voltage Rating: 250 VAC / 125 VDC
• Amperage Rating: 1 A
• Interrupt Rating: 50 kA
• Construction: Melamine Body
