Bussmann MDA-15-R FUSE TD NON-INDICATING NON-REJECTION 15A

Product Description

The Bussmann MDA-15-R is a small dimension time delay fuse designed for various electrical applications. Rated at fifteen amperes, it operates at a voltage of two hundred fifty volts. The fuse is built with a ceramic body and features nickel plated brass end caps. It has a cylindrical shape and is characterized as non-indicating and non-rejection type. The response time is sixty minutes at one hundred thirty-five percent and one hundred twenty seconds at two hundred percent. This makes it suitable for controlling inrush currents in diverse electronic circuits.

• Ceramic body for durability and higher ratings
• Compact size allows for flexible installation
• Meets requirements for electronic fuse applications

Product Highlights

The Bussmann MDA-15-R fuse provides reliable performance in a variety of electrical systems, ensuring protection against overloads.

Product Information

Standard Information

• Brand: Bussmann
• MPN: MDA-15-R

Technical Specifications

• Voltage Rating: 250 VAC
• Amperage Rating: 15 A
• Interrupt Rating: 750 A/10 kA
• Response Time: 60 min, 120 s
• Body Size: 1/4 in Dia x 1-1/4 in L
• Material: Ceramic
• Terminal Type: Ferrule
• Mounting Type: Holder
