Bussmann LPJ-90SPI 600V TD TB FS

Product Description

The Bussmann LPJ-90SPI is a Class J fuse with a time-delay feature. This fuse operates at a voltage rating of 600 volts and offers a dual-element current limiting capability. It has a 90 ampere rating suitable for various electrical applications. The LPJ-90SPI is designed for use in facilities needing reliable safety and security systems.

• Time-delay for enhanced overload protection
• Interrupting rating of 300 kA at 600 Vac
• Non-indicating design for high in-rush current motor protection

Product Highlights

The Bussmann LPJ-90SPI fuse provides essential protection for electrical systems in industrial settings. Its dual-element design allows for effective current limitation, ensuring safe operation of connected loads.

Product Information

Standard Information

• Manufacturer: Bussmann
• Family Group: Fuses/Accessories

Technical Specifications

• Voltage Rating: 600 Vac; 300 Vdc
• Amperage Rating: 90 A
• Dimensions: 4.63 inches x 1.13 inches x 1.13 inches
• Interrupt Rating: 300 kAic at 600 Vac; 100 kAic Vdc
• Connection: Bolted blade end x bolted blade end
• Response Time: 10 seconds at 500%
• Special Features: High in-rush current motor protection; Non-indicating
• Standard Compliance: CE Marked; RoHS Compliant
