Bussmann LP-CC1-1/2 600v 1-1/2amp Current-Limiting, Time-Delay Class-CC Fuse

Product Description

The Bussmann LP-CC1-1/2 is a current-limiting, time-delay fuse with a voltage rating of six hundred volts. Designed for specialized circuits, this fuse offers a reliable performance in industrial control applications. The MPN for this item is LP-CC1-1/2.

• Meets CE, CSA, and UL 248-4 standards.
• Rated for one point five amps with a response time of twelve seconds at two hundred percent.
• Features a dual-element construction for enhanced safety.

Product Highlights

This fuse provides a reliable protection in critical electrical applications, making it ideal for safety and security systems in industrial facilities.

Product Information

Standard Information

• Brand: Bussmann
• Manufacturer: Bussmann Mfg.

Technical Specifications

• Catalog Number: LP-CC1-1/2
• Voltage Rating: 600 Vac; 300 Vdc
• Amperage Rating: 1.5 A
• Type: Current Limiting, Time-Delay
• Material: Melamine
• Diameter: 0.46 Inch
• Dimensions: 1.5000 in x 0.4100 in x 0.4100 in
• Interrupt Rating: 200 kAIC at 600 Vac; 20 kAIC at 300 Vdc
