Bussmann LP-CC-6/10 Low Peak Time Delay Fuse

Product Description

Bussmann LP-CC-6/10 is a low peak time delay fuse designed for current limiting. This model meets high standards with a dual-element design and a voltage rating of three hundred volts. This fuse is suitable for various applications, especially in specialized circuits and industrial control.

• Time delay feature with a response time of twelve seconds at two hundred percent.
• Interrupt rating of twenty kAIC at one hundred fifty volts DC and two hundred kAIC at six hundred volts AC.
• Ferrule connection type for easy installation.

Product Highlights

This Bussmann fuse offers reliable performance and safety for your electrical systems.

Product Information

Standard Information

• Brand: Bussmann
• Manufacturer: Bussmann Mfg.

Technical Specifications

• Catalog Number: LP-CC-6/10
• Type: Current Limiting, Time-Delay
• Amperage: 0.6 A
• Voltage Rating: 300 Vdc; 600 Vac
• Diameter: 0.46 inches
• Length: 1.5 inches
• Material: Melamine
• Response Time: 12 sec at 200%
• Connection Type: Ferrule end x ferrule end
• Interrupt Rating: 20 kAIC at 150 Vdc, 200 kAIC at 600 Vac
