Bussmann LP-CC-2-1/2 600v 2-1/2amp Current-Limiting, Time-Delay Class-CC Fuse

Product Description

The Bussmann LP-CC-2-1/2 is a current-limiting, time-delay fuse designed for use in both residential and commercial applications. Rated for two and a half amps and up to six hundred volts, this fuse is suitable for various specialized circuits and industrial control settings. The LP-CC-2-1/2 features dual-element construction, which helps prevent nuisance tripping.

• Voltage Rating: 600 Vac and 300 Vdc
• Interrupt Rating: 20 kAIC
• Applications: Isolated, specialized circuits, and in-line fuse holders

Product Highlights

This fuse is UL listed and RoHS compliant, ensuring safety and environmental standards. With a response time of twelve seconds at two hundred percent, it provides efficient protection in critical circuits.

Product Information

Standard Information

• Brand: Bussmann
• Manufacturer: Bussmann Mfg.

Technical Specifications

• Amperage: 2-1/2 Amp
• Type: Time-Delay, Current Limiting
• Diameter: 0.46 Inch
• Length: 1-1/2 Inch
• Material: Melamine
• Application: Specialized Circuits, In-Line Fuse Holder
• End Type: Ferrule
