Bussmann LP-CC-10 Low-Peak 150/600V Time Delay Fuse

Product Description

The Bussmann LP-CC-10 is a time delay fuse rated for 10 Amps and designed for use in various electrical applications. This fuse operates at 600 Volts AC and 150 Volts DC. It has a high interrupt rating of 200 Kilo-Amps for AC and 20 Kilo-Amps for DC, ensuring effective protection against short-circuit current overloads.

• Features a dual-element design for optimized time delay performance
• Constructed with a durable melamine body for reliable operation
• UL listed and compliant with CSA, CE, and RoHS standards

Product Highlights

The Bussmann LP-CC-10 is ideal for use in branch circuits, industrial control systems, and street lighting. Its rejection-style feature ensures compatibility with Class CC fuse blocks, making it a safe choice for circuits requiring time delay and current limitation.

Product Information

Standard Information

• Brand: Bussmann
• MPN: LP-CC-10

Technical Specifications

• Type: Rejection, Current-Limiting
• Voltage Rating: 600 Vac, 150 Vdc
• Amperage Rating: 10 Amps
• Interrupt Rating: 200 Kilo-Amp at 600 Vac, 20 Kilo-Amp at 150 Vdc
• Dimensions: 0.41 inches diameter x 1.5 inches length
• Construction: Melamine body
• Mounting: Clip
• Response Time: 12 seconds at 200% rated load
