Bussmann KTK-40 Fuse 40A 600V

Product Description

The BUSSMANN KTK-40 is a series KTK fuse designed for control circuits, lighting circuit protection, and meter circuits. This 40A, 600V fast-acting fuse features a melamine tube and nickel-plated bronze endcaps with ferrule end connections. Its small footprint makes it suitable for various applications. It has a 10 kiloampere interrupting rating at 600Vac.

• Small footprint
• Fast acting supplemental fuse
• Ferrule end x ferrule end connection

Product Highlights

The BUSSMANN KTK-40 fuse is ideal for protecting control circuit transformers and other sensitive equipment.

Product Information

Standard Information

• Brand: BUSSMANN
• Manufacturer Part Number: KTK-40
• Country of Origin: China

Technical Specifications

• Product Name: Eaton Bussmann series KTK fuse
• Catalog Number: KTK-40
• UPC: 051712420327
• EAN: 5027590445979
• Product Length/Depth: 0.41 in
• Product Height: 1.5 in
• Product Width: 0.41 in
• Compliances: CE Marked
• RoHS Compliant: RoHS Compliant
• Product Type: Fuse
• Amperage Rating: 40 A
• Voltage rating: 600 V
• Material: Melamine tube Nickel-plated bronze endcap
• Packaging type: Standard
• Connection: Ferrule end x ferrule end
• Fuse indicator: Non-indicating
• Special features: Small footprint
• Brand: Eaton Bussmann
• Series: KTK
• Mpn: KTK-40
• Gtin: 51712420327
• Application: Control circuits, lighting circuit protection, meter circuits
• End Type: Ferrule End x Ferrule End
• Fuse Dimension: 1-1/2 L x 13/32 in. Dia.
• Rated Voltage: 600V
• Fuse Amps: 40A
• Length: 0.41 in.
• Height: 1.5 in.
• Width: 0.41 in.
• Voltage Rating - AC: 600 VAC
• Response Time: Fast Blow
• Applications: Electrical, Industrial
• Approval Agency: CSA, UL
• Breaking Capacity @ Rated Voltage: 100kA
• Mounting Type: Requires Holder
• Package / Case: 5AG, 10mm x 38mm (Midget)
• Fuse Type: Cartridge
• Size / Dimension: 0.406" Dia x 1.500" L (10.30mm x 38.10mm)
• Current Rating (Amps): 40A
