Bussmann KTK-2/10 Fuse, Midget, 2/10A, KTK Series

Product Description

The BUSSMANN KTK-2/10 is a Midget fuse with a 2/10A rating and belongs to the KTK Series. It provides thermal overload protection. This fast-acting supplemental fuse is non-indicating and has an interrupt rating of 100kAIC at 600Vac. Ideal for control circuits, lighting circuit protection, and meter circuits.

• Thermal Overload Protection
• Fast Acting
• Interrupt Rating: 100 kAIC

Product Highlights

The BUSSMANN KTK-2/10 fuse is fast acting and provides reliable circuit protection.

Product Information

Standard Information

• Brand: BUSSMANN
• Manufacturer Part Number: KTK-2/10
• Country of Origin: China

Technical Specifications

• Type: Time Delay Midget Fuses
• Brand: Bussmann
• Current Type: AC/DC
• Features: Thermal Overload Protection
• Country of Origin: China
• Amperage: 2/10 Amp
• Applications: Electrical, Industrial
• Connection Type: Ferrule End X Ferrule End
• Interrupt Rating: 100 kAIC
• Material: Melamine
• Size: 13/32 In Diameter X 1-1/2 In Length
• Standard: CE,UL 248-14,CSA C22.2
• Voltage: 600 Volt
• Sub Brand: Limitron
• Class: Supplemental
• Ac Voltage Rating: 600V AC
• Amps: 2/10A
• Body Material: Melamine
• Body Style: Cylindrical
• Compatible Fuse Block Series: Bc, Bcm, C2617, C5268, Chcc, Hpf, Opm-1038, Opm-Ng
• Diameter: 13/32"
• Element: Single
• Equivalent Brand And Series: Bussmann KTK-R, Littelfuse KLKR, MERSEN ATMR Series
• Equivalent Series: Atmr, Klkr, Ktk-R
• Fits Fuse Block Style: Rejection
• Fuse Size (lg X Dia): 1 1/2" x 13/32"
• Indicating / Nonindicating: Non Indicating
• Length: 1 1/2"
• Overall Diameter: 13/32"
• Rejection / Nonrejection: Rejection
• Series: KTK-R Series
• Speed: Fast Acting
• Speed Type: Fast Acting
• Standards: Ce/Ul-248-4 Guide Jddz/Csa Class 1422-02
• Visual Indication: Non Indicating
• Category: Circuit Protection
• Electrical, Specialty Fuses: Electrical, Specialty Fuses
• Voltage Rating - AC: 600 VAC
• Manufacturer: Eaton - Bussmann Electrical Division
• Response Time: Fast Blow
• Approval Agency: CSA, UL
• Part Status: Active
• Breaking Capacity @ Rated Voltage: 100kA
• Mounting Type: Requires Holder
• Package / Case: 5AG, 10mm x 38mm (Midget)
• Fuse Type: Cartridge
• Size / Dimension: 0.406" Dia x 1.500" L (10.30mm x 38.10mm)
