Bussmann JP60030-3PR Fuse Block 30 A

Product Description

The Eaton Bussmann series JP60030-3PR pyramid fuse block is rated for 30 A, Class J, and 600 Vac/dc. With a 200 kA interrupt rating and constructed from thermoplastic, it is suitable for panel mounting. It accepts #14-10 AWG Cu/Al wire and is designed for use with LPJ, DFJ, and JKS fuses.

• 200 kAIC Short-circuit rating
• Thermoplastic construction
• For use with LPJ, DFJ, JKS fuse

Product Highlights

The Bussmann JP60030-3PR fuse block offers reliable protection for industrial and commercial power systems with its open-top design for quick fuse access.

Product Information

Standard Information

• Brand: BUSSMANN
• Manufacturer Part Number: JP60030-3PR
• Country of Origin: Mexico

Technical Specifications

• Product Name: Eaton Bussmann series JP pyramid fuse block
• Catalog Number: JP60030-3PR
• UPC: 051712434188
• Product Length/Depth: 4 in
• Product Height: 2.5 in
• Product Width: 3 in
• Compliances: RoHS Compliant
• Product Type: Pyramid fuse block
• Amperage Rating: 30 A
• Interrupt rating: 200 kAIC
• Short-circuit rating: 200 kA
• Voltage rating: 600 Vac, 600 Vdc
• Material: Thermoplastic
• Wire size: #14-10 AWG Cu/Al
• Class: Class J
• Connection: Screw/pressure plate
• Mounting method: Panel
• Used with: For use with LPJ, DFJ, JKS fuse
• Brand: BUSSMANN
• MPN: JP60030-3PR
• AC Voltage Rating: 600 V
• Compatible Fuse Series: A4J, AJT, DFJ, HSJ, JKS, JLS, JTD, JTD-ID, LDFJ, LPJ, LPJ-I
• Current - Maximum: 30 A
• Current - Minimum: 0 A
• Features: Space Saving Design
• Compatible Fuse Class or Type: Class J
• Compatible Fuse Diameter: 13/16 in
• Compatible Fuse Length: 2-1/4 in
• Fuse Block Terminal Type: Pressure Plate
• Fuse Block Design: Open Pyramid
• Fuse Block Mounting Style: Bolt-Down
• Fuse Block Style: Non-Rejection
• Number of Poles: 3
• Overall Height: 2.78 in
• Overall Length: 3.75 in
• Overall Width: 3.29 in
• Standards: CE; CSA Certified; UL Listed
• Visual Indication: Non-Indicating
• Wire Size - Maximum: 10 AWG
• Wire Size - Minimum: 14 AWG
• UNSPSC: 39121411
• Certifications: UL Listed CSA Certified
