Bussmann JJS-175 TRON FA FS Class T Fuse 175 A

Product Description

The Bussmann JJS-175 fuse is a current-limiting Class T fuse designed for various applications requiring reliable protection. This fuse is rated for 175 amperes and features a small footprint, making it suitable for tight spaces. It provides VFD line protection and is constructed with bolted blade ends for secure connections.

• Current-limiting design for enhanced safety
• Rated for 175 A with a standard voltage of 600 V
• Compact size for easy installation in limited spaces

Product Highlights

This fuse is ideal for industrial facilities and safety systems, ensuring protection against overloads and short circuits.

Product Information

Standard Information

• Manufacturer: Bussmann
• UPC: 05171262817

Technical Specifications

• Fuse Type: Class T
• Amperage Rating: 175 A
• Voltage Rating: 600 V
• Interrupt Rating: 200 kAIC at 600 Vac
• Dimensions: 3.25 in Length x 0.88 in Diameter
• Connection Type: Bolted blade end x bolted blade end
• Weight: 0.2 lbs
• Compliance: RoHS Compliant, CE Marked
